R_volution Chassis DIY-X700
Ultimate DIY Upgrade Kit for Sony UBP‑X700 4K Ultra HD Blu‑ray™ player
Transform your Sony UBP‑X700 into an ultimate high‑end 4K Ultra HD Blu‑ray™ player by equipping it with a linear power supply featuring a massive toroidal transformer and audiophile‑grade electronic components, ensuring improved picture quality and superior digital audio performance specially optimised by Authentic Cinema.
This DIY kit allows you to upgrade your Sony UBP‑X700 easily, transforming it into a higher‑performance player through a clear and easy‑to‑follow installation process. No technical skills are required: simply open the original unit, remove the mainboard and optical drive, then install the new components into the beautifully crafted chassis and connect the included ribbons and cables.
Every step is fully documented with a detailed manual and a video, ensuring a smooth and stress‑free experience. In just a few minutes, your player is ready to deliver enhanced performance.
The R_volution Chassis DIY-X700 Signature Edition is an upgraded version of the R_volution Chassis DIY-X700 with premium electronic components.
Enhanced Upgrade Package
Technical Improvements Over the Original Design:
-
Installation of an inlet EMI filter to reduce high‑frequency interference.
-
Addition of a power line ferrite filter for improved noise suppression.
-
Replacement of all rectifier diodes with high‑end, soft‑recovery versions.
-
Upgrade of the main PSU buffer capacitors to premium models with increased reserve capacity. Integration of additional filtering elements within the power supply for enhanced stability.
-
Addition of a ferrite filter to the front‑panel cable to minimize conducted noise. Installation of a special high‑grade capacitor on the contact board for improved electrical consistency.
-
Application of vibration‑damping material to the bottom chassis panel.
-
Replacement of the original AC inlet with a Furutech Rhodium‑plated power inlet for superior conductivity and mechanical integrity.
-
Substitution of the standard fuse with a ceramic fuse featuring gold‑plated end caps.
-
Replacement of the plastic feet with our precision‑machined aluminum feet for improved rigidity and vibration control.
-
Application of a special anti‑vibration sealing compound to the capacitors to reduce micro‑resonances.
Designed for Ultimate Home Theater Experience
Thanks to its high-quality internal power supply specifically calibrated for digital audio and video transport, the R_volution Chassis DIY-X700 offers breathtaking image quality, deep blacks, vibrant colors, exceptional image sharpness and extremely dynamic digital multi-channel sound quality and precision with a wide dynamic range.
Vivid Colors
Linear Power Supply with a Robust Toroidal Transformer.
The R_volution Chassis DIY-X700 Signature Edition features a high-performance power supply equipped with a Toshiba linear voltage regulator and powered by a massive 81W oxygen-free copper toroidal transformer, ensuring a noise-free signal for enhanced image quality, more accurate color grading, deeper blacks, and superior audio and visual precision. The Chassis DIY-X700 also uses a low dropout (LDO) linear voltage regulator from Lintec. The power supply features upgraded premium buffer capacitors with increased reserve capacity, complemented by additional filtering elements that further enhance electrical stability.
Best of the Best
The Chassis DIY-X700 uses high-performance components including:
-
Nichicon and Nippon Chemical's dedicated audio capacitors.
-
WIMA video specific capacitors.
Remote control and Integration.
The R_volution Chassis DIY‑X700 comes with a larger IR remote than the original, offering additional control buttons.
The R_volution Chassis DIY‑X700 is engineered for seamless operation in high‑end installations and custom integrations. Because the remote control uses the same IR codes as the original Sony player, it can be effortlessly integrated into leading control ecosystems such as RTI, Control4, ProControl, Crestron, Savant, Philips Pronto, Elan, URC, Sofabato, Tuya, SwitchBot and Logitech Harmony.
Rack‑mount ears are also included for premium custom rack installations. To ensure optimal performance, the chassis includes a dedicated ground connector that eliminates ground‑loop interference when installed in a rack environment.
Dimensions (W × H × D)
16.93 × 11.11 × 2.82 in (without carton)
43.0 × 28.23 × 7.17 cm (without carton)
8.37 × 6.12 × 3.41 in (with carton)
49.5 × 34.0 × 20.0 cm (with carton)
Weight
7.8KG / 11.02 lbs (with carton)
5KG / 17.20 lbs (without carton)
Limited Warranty
2 years
Certification
RoHS, CE, FCC
Country of Origin
Design: France
Production: China
Chassis DIY-X700
EAN: 3760115010093
Chassis DIY-X700 + Sony X700
EAN: 3760115010109
Chassis DIY-X700 + Sony X700 MRZ
EAN: 3760115010116
TARIC Number
8504 40 30 00
Model
RVRX700
Operating Temperature
10~30°C
Operating Humidity
30%~70%
Consumption
Playbacl: 12W
Standby: 0.5W
Internal Power Supply
AC 100-240V
Accessories
● IR Remote
● 1 m 4K HDMI cable
● Rack Mount Kit
● Power cables ×4 (EU, US, UK, AU)
